Product Type Desktop MATX PCBA with ZX-E
Dimensions M-ATX板型: 225 x 182mm
Processor 兆芯 KX-U6780A, 2.7G, 70W, 8C
Graphic External GFX option (xxx)
WLAN Option (From PCIEx1)
Memory UDIMM DDR4 (2666) x 2
Storage M.2 PCIe SSD / 2.5〞 SATA HDD
I/O Ports
4 x USB2.0
1 x PS/2
1 x COM
1 x VGA
1 x HDMI
2 x USB 3.1
1 x RJ45
1 x Line in, 1 x Line out, 1 x Mic
Inner
Connector
ATX POWER CON 24+4
2 x SATA3 6Gb/s
1 x M.2/PCIE (SSD)
1 x PCIEx16 3.0 (x8 signal
support)
2 x PCIEx1 2.0
1 x USB3.1 (2*10) Header
2 x USB2.0 (2*5) Header
1 x COM (2*5) Header
1 x Audio (2*5) Header
1 x CPU FAN Header
2 x System FAN Header
1 x LPT (2*13) Header
Power switch/Power
LED/HDD LED/Reset
Header
1 x TCM (2*10) Header
OS Linux / Windows

产品参数:ZX-E 国产芯片主板,基于兆芯KX-U6780A,2.7G,70W,8C的国产芯片主板
