Processor Intel® Xeon D
Chipset Integrated
Memory
Dual Channel R/U ECC DIMM(x4) DDR3L
1600MHz
Max 64GB
Storage
1 x M.2 2242/2280 NVME PCIE 3.0 x4
SSD, SATA 3.0 Auto detect
12 x SATA 3.0(3 x 8087)
Graphics 2D VGA
Wireless 1 x MINIPCIE for Wifi Module
PCIE Slots 1 x PCIE 3.0 X16; 1 x PCIE 3.0 X4;
Network 4 x I210AT Intel 1000M Ethernet
Audio C-Media CM109 HD Audio Codec
Front I/O
1 x 3.5mm Line out
1 x 3.5mm Mic in
2 x USB 3.0
2 x USB 2.0
1 x Power button
1 x Power LED
1 x HDD/SSD LED
1 x Reset button
1 x UART
Real I/O
2 x USB 3.0
4 x USB 2.0
2 x RJ45 1000M Ethernet
1 x 3.5mm Line out
1 x 3.5mm Line in
Power input ATX 24+4
Material Metal
Dimensions 244(L) x 185(W)
Temperature Operating -5℃~45℃
Storage -20℃~70℃
Relative
humidity 10%~95% （ non-condensing）
Net Weight 0.4kg （ non-final）
